Model
SC02-I565A
SC02-I575A
SC02-I586A
-
Screen
-
Screen Size
SC02-I565A: 65-inch
SC02-I575A: 75-inch
SC02-I586A: 86-inch
-
Screen Type
SC02-I565A: VA
SC02-I575A: ADS
SC02-I586A: IPS
-
Backlight
D-LED
-
Backlight Life
50,000 hours (min.) (typ.)
-
Resolution
3840 × 2160 (pixels)
-
Brightness
SC02-I565A: 350cd/m² (typ.)
SC02-I575A: 400cd/m² (typ.)
SC02-I586A: 400cd/m² (typ.)
-
Contrast Ratio
SC02-I565A: 4000:1 (typ.)
SC02-I565A: 5000:1 (typ.)
SC02-I586A: 5000:1 (typ.)
-
Response Time
8ms (typ.)
-
Frequency
60Hz
-
Aspect Ratio
16:09
-
Viewing Angle
178°(H) / 178°(V)
-
Display Color
1.07B(8bit+FRC)
-
Bonding Technology
The gap between tempered glass and screen is close to 0
-
Touch
-
Touch Technology
High Precision IR
-
Touch Points
Up to 50
-
Touch Response Time
≥2ms
-
Touch Accuracy
Center 90% touch area: 1mm
-
Anti-Glare
High transparent+Smooth+Anti-glare
-
Glass Hardness
9H (Pencil Hardness) ; 7(Mohs Hardness) Tempered Glass
-
Writing Height
≤ 1mm
-
System
-
CPU
Quad core A73+Quad core A53
-
GPU
MaliG52 MP8
-
Memory (RAM)
8GB (up to 16GB)
-
Storage (ROM)
128GB (up to 256GB)
-
Operating System
Android 13 (standard)/ Windows 11 (Optional)
-
Connectivity
-
Front Port
USB 3.0*2; Type-C(65W)*1; Touch*1; HDMI IN: 1
-
Bottom Port
USB 2.0*1; DP IN*1; Touch*1; RS232*1; LAN*2; SPDIF*1
-
Side Port
AUDIO IN*1; AUDIO OUT*1; Type-C OUT*1; USB 3.0*2; Touch * 1; HDMI IN: 3; HDMI OUT*1; Type-C(65W)*1; OPS slot (for slot-in PC)*1
-
Built-in peripherals
-
WiFi+Bluetooth
WiFi 6: 802.11 ax/b/g/n/ac
BT 5.2: 2.1+EDR/4.2/5.2
-
NFC
ISO / IEC 14443 Type A & Type B cards
-
Camera
Pixel: 48 MP
POV: FOV Diagonal 106°
Face Tracking: Support
Sound localization: Support
-
Microphone
Array Quantity: 8 microphones array(up to 12m)
Pickup Range: Support
3D Noise Reduction: Support
AEC & AGC: Support
-
Speaker
2x8W + 2x18W
-
Operating Power
100 V ~ 240 V/AC, 50/60 Hz
-
Standby power consumption
<0.5W
-
Power Consumption (typ.) (100% Brightness)
SC02-I565A: 200W
SC02-I575A: 300W
SC02-I586A: 550W
-
Physical
-
Dimensions (W × H × D)
SC02-I565A:1488 x 86 x 915 mm
SC02-I575A: 1709 x 86 x 1039 mm
SC02-I586A: 1957 x 98.5 x 1179 mm
-
Package Dimensions (L × W × H)
SC02-I565A: 1628 x 208 x 1014 mm
SC02-I575A: 1863 x 225 x 1163 mm
SC02-I586A: 2110 x 225 x 1304 mm
-
Net Weight (kg)
SC02-I565A: 40 kg
SC02-I575A: 52.5 kg
SC02-I586A: 64 kg
-
Weight with Packaging (kg)
SC02-I565A: 52 kg
SC02-I575A: 64 kg
SC02-I586A: 84 kg
-
Case Material
Aluminium Alloy and Sheet Metal
-
Color
Blue Grey
-
Environment
-
Operating Temperature
0°C to 40°C
-
Storage Temperature
10°C to 60°C
-
Operating Humidity
20% to 80% RH (Non-condensing)
-
Storage Humidity
10% to 60% RH (Non-condensing)
-
Accessories
-
Cables
Power Cable*1, USB Cable*1, HDMI Cable*1
-
Remote Controller
1
-
Wall mount
1
-
Stylus Pen
2
-
Eraser
1
-
Peripheral Accessories(Optional)
-
Movable bracket
YES
-
OPS
YES
-
Wireless Dongle
YES
-
Fonts Library
