Parameters

• Model

  SC02-I565A
  SC02-I575A
  SC02-I586A

• Panel

• Screen Size

  SC02-I565A: 65-inch
  SC02-I575A: 75-inch
  SC02-I586A: 86-inch

• Screen Type

  SC02-I565A: VA
  SC02-I575A: VA
  SC02-I586A: IPS

• Backlight

  D-LED

• Resolution

  3840 × 2160 (pixels)

• Brightness

  SC02-I565A: 350cd/m² (typ.)
  SC02-I575A: 400cd/m² (typ.)
  SC02-I586A: 400cd/m² (typ.)

• Contrast Ratio

  SC02-I565A: 4000:1 (typ.)
  SC02-I565A: 5000:1 (typ.)
  SC02-I586A: 5000:1 (typ.)

• Response Time

  8ms

• Frequency

  60Hz

• Aspect Ratio

  16:9

• Backlight Life

  50,000 hrs

• Glass Hardness

  9H (Pencil) 7 (Mohs)

• Glass Type

  Anti-glare

• Viewing Angle

  178°(H) / 178°(V)

• Touch

• Touch Technology

  High Precision IR

• Touch Points

  Up to 50

• Touch Response Time

  ≤2ms

• Touch Accuracy

  Center 90% touch area: ±0.5mm

• Touch Object Recognition Range (Min)

  Single touch: ≥1.5mm

• Writing Height

  ≤ 1mm

• System

• CPU

  Arm Cortex-A76*4 Cortex-A55 *4 (≥2.4Ghz)

• GPU

  Mali-G610 MP4

• Memory (RAM)

  8GB (up to 16GB)

• Storage (ROM)

  128GB (up to 256GB)

• Operating System

  Android 15.0 & Windows 11 (Optional)

• Connectivity

• Front Port

  USB 3.0*2; Type-C(65W)*1; Touch*1; HDMI IN: 1

• Bottom Port

  USB 2.0*1; DP IN*1; Touch*1; RS232*1; LAN*2; SPDIF*1

• Side Port

  AUDIO IN*1; AUDIO OUT*1; Type-C OUT*1; USB 3.0*2; Touch * 1; HDMI IN: 3; HDMI OUT*1; Type-C(65W)*1; OPS slot (for slot-in PC)*1

• Built-in peripherals

• WiFi+Bluetooth

  WiFi 6: 802.11 ax/b/g/n/ac
  BT 5.2: 2.1+EDR/4.2/5.2

• NFC

  ISO/ IEC 14443 A/ ISO/ IEC 14443 B

• Camera

  Pixel: 48 megapixels
  POV: FOV Diagonal 106°
  Face Tracking: Support
  Sound localization: Support

• Microphone

  Array Quantity: 8 microphones array(up to 12m)
  Pickup Range: Support
  3D Noise Reduction: Support
  AEC & AGC: Support

• Speaker

  2x8W + 2x18W

• Operating Power

  100 V ~ 240 V/AC, 50/60 Hz

• Standby power consumption

  <0.5W

• Power Consumption (typ.) (100% Brightness)

  SC02-I565A: 200W
  SC02-I575A: 300W
  SC02-I586A: 550W

• Physical

• Dimensions (W × H × D)

  SC02-I565A:1488 x 86 x 915 mm
  SC02-I575A: 1709 x 86 x 1039 mm
  SC02-I586A: 1957 x 98.5 x 1179 mm

• Package Dimensions (L × W × H)

  SC02-I565A: 1628 x 208 x 1014 mm
  SC02-I575A: 1863 x 225 x 1163 mm
  SC02-I586A: 2110 x 225 x 1304 mm

• Net Weight (kg)

  SC02-I565A: 40 kg
  SC02-I575A: 52.5 kg
  SC02-I586A: 64 kg

• Weight with Packaging (kg)

  SC02-I565A: 52 kg
  SC02-I575A: 64 kg
  SC02-I586A: 84 kg

• Case Material

  Aluminium Alloy and Sheet Metal

• Color

  Black grey

• Environment

• Operating Temperature

  0°C to 40°C

• Storage Temperature

  10°C to 60°C

• Operating Humidity

  20% to 80% RH (Non-condensing)

• Storage Humidity

  10% to 60% RH (Non-condensing)

• Accessories

• Cables

  Power Cable*1, USB Cable*1, HDMI Cable*1

• Remote Controller

  1

• Wall mount

  1

• Stylus Pen

  2

• Peripheral Accessories(Optional)

• Movable bracket

  YES

• OPS

  YES

• Wireless Dongle

  YES
