Parameters

• General Specifications

• Tunnel Size

  600mm * 400mm (W x H)

• Conveyor Speed

  0.30 m/sec

• Conveyor Load

  120kg (Adequate distribution) (Max. Load)

• Conveyor Height

  680 mm

• Detector

  Single-energy Detector

• View

  Single-view

• Supported Software

  ZKBio SIS

• Communication Interface

  RJ45(TCP/IP)

• Dimensions (L*W*H)

  1701mm * 910mm * 1305mm

• Package Dimensions (L*W*H)

  2110mm * 1140mm * 1540mm

• Gross Weight

  480kg (with Package)

• Net Weight

  380kg

• Film Safety

  ASA/ISO1600

• Certifications

  CE-EMC, CE-MD

• X-ray Generator & Image Performance

• Anode Voltage

  80 kV

• Tube Current

  0.6 mA

• Wire Resolution

  36AWG

• Steel Penetration

  8mm

• Spatial Resolution

  HorizontalΦ1.3mm/VerticalΦ1.3mm

• Penetration Resolution

  30AWG

• Generator Cooling

  Sealed Oil Bath with Forced Air

• Beam Direction

  Vertically Upward

• X-ray converter type

  L-shaped Detector Line

• Computer Specification

• Operating System

  Windows 10

• Processor

  N100

• RAM

  8 GB

• Hard Drive

  128GB SSD + 2TB HDD

• Max. Storage

  Up to 200,000 Scanned Images

• Monitor

  21.5"Color LED Screen (1920*1080P)

• Operating Environment

• System Power

  220 VAC +/- 10% 50/60Hz
  110 VAC +/- 10% 50/60Hz

• Power Consumption

  < 300W

• Noise Level

  < 58 dB(A)

• Operating Temperature

  -10°C to +45°C

• Storage Temperature

  -20°C to +60°C

• Working Humidity

  5-95%, Non-condensing

• Health & Safety

• Radiation Leak Dosage

  < 0.3 μSv/h (10cm From the Surface)
