Parameters

• Model

  ZKUPS-900W-R
  ZKUPS-1800W-R
  ZKUPS-2700W-R

• Capacity

  ZKUPS-900W-R: 1 KVA/900 W
  ZKUPS-1800W-R: 2 KVA/1.8 KW
  ZKUPS-2700W-R: 3 KVA/2.7 KW

• Battery Voltage

  ZKUPS-900W-R: 24 V
  ZKUPS-1800W-R: 48 V
  ZKUPS-2700W-R: 72 V

• Dimensions(L*W*H)

  ZKUPS-900W-R: 360 × 438 × 88
  ZKUPS-1800W-R: 498 × 438 × 88
  ZKUPS-2700W-R: 498 × 438 × 88

• Net Weight

  ZKUPS-900W-R: 11 kg
  ZKUPS-1800W-R: 15.2 kg
  ZKUPS-2700W-R: 20 kg

• Input

• Voltage

  55 to 145 VAC

• Frequency Range

  50 to 60 Hz

• Phase

  Single Phase With Ground

• Power Factor

  ≥ 0.99 @ 100% Load

• Output

• Voltage Range

  120 VAC (± 1%)

• Frequency Range

  46 to 54 Hz synchronised; 50 Hz (Battery)

• Current Crest Ratio

  3:1

• Output Current

  ZKUPS-900W-R: 4.5 A
  ZKUPS-1800W-R: 9.1 A
  ZKUPS-2700W-R: 13.6 A

• Harmonic Distortion

  ≤ 4% THD (Linear Load); ≤ 7% THD (Non-linear Load)

• Overload

  105% ± 5% < Load ≤ 125% ± 5%: after 50 seconds transfer to bypass and alarm;
  125% ± 5% < Load ≤ 150% ± 5%: after 25 seconds transfer to bypass and alarm;
  Load >150% ± 5%: after 300 ms transfer to bypass and alarm

• Transfer Time

  0 (AC mode to batt. mode)

• Wave Form (Battery Mode)

  Pure Sinewave

• Battery

• Battery Type

  12 V/7 AH

• Battery Numbers

  ZKUPS-900W-R: 2
  ZKUPS-1800W-R: 4
  ZKUPS-2700W-R: 6

• Recharge Time

  8 hours recover to 90% capacity

• Charging Current

  1 A

• Management

• Smart RS-232

  Support Windows® 2000/2003/XP/Vista/2008,Windows® 7/8, Linux, Unix and MAC

• Optional SNMP

  Power management from SNMP management and web browser

Download

(Silver and above members can download after logging in)

• Name
• Type
• Size
• Update Time

• PDF

  Online High Frequency UPS_Datasheet_20251209

  Datasheet

  357.55KB

  2025-12-25

  Download
