Model
ZKUPS-720W-LCD
ZKUPS-900W-LCD
ZKUPS-1200W-LCD
ZKUPS-1800W-LCD
-
Capacity
ZKUPS-720W-LCD: 1200 VA/ 720 W
ZKUPS-900W-LCD: 1500 VA/ 900 W
ZKUPS-1200W-LCD: 2000 VA/ 1200 W
ZKUPS-1800W-LCD: 3000 VA/ 1800 W
-
Input
-
Voltage
110 V/120 VAC or 220/230/240 VAC
-
Voltage Range
81 to 145 VAC or 145 to 275 VAC
-
Power Factor
≥ 0.99 @ 100% Load
-
Frequency
60/50 Hz (Auto sensing)
-
Output
-
Voltage
110/120 VAC or 220/230/240 VAC
-
Voltage Range
± 10%
-
Frequency Range (Battery Mode)
60/50 ± 1 Hz
-
Transfer Time
4 to 6 ms
-
Wave Form (Battery Mode)
Simulated Sine Wave
-
Battery
-
Battery Model & Quantity
ZKUPS-720W-LCD: 12 V/7 AH × 2
ZKUPS-900W-LCD: 12 V/9 AH × 2
ZKUPS-1200W-LCD: 12 V/9 AH × 2
ZKUPS-1800W-LCD: 12 V/9 AH × 4
-
Charge Time
8 hours recover to 90% capacity
-
Protection
-
Full Protection
Discharge, Short circuit, Overload protection
-
Indicator
-
LCD Display
AC mode, Battery mode, Load level, Battery level, Input voltage, Output voltage, Overload and low battery
-
Alarm
-
Battery Mode
Sounding every 4 seconds
-
Low Battery
Sounding every second
-
Overload
Sounding every second
-
Fault
Continuously sounding
-
Interface
-
USB / R232 Port (Optional)
Support windows XP/Vista, Windows 7/8, Linux, Unix, and MAC
-
Optional SNMP
Power management from SNMP management and web browser
-
Environmental
-
Operating Humidity
0-90% RH @ 0-40 °C (Non-condensing)
-
Noise Level
Less than 40 dB
-
Dimensions
ZKUPS-720W-LCD: 365 × 140 × 165 (mm)
ZKUPS-900W-LCD: 365 × 140 × 165 (mm)
ZKUPS-1200W-LCD: 365 × 140 × 165 (mm)
ZKUPS-1800W-LCD: 395 × 145 × 210 (mm)
-
Weight
ZKUPS-720W-LCD: 9.9 kg
ZKUPS-900W-LCD: 12.6 kg
ZKUPS-1200W-LCD: 13.2 kg
ZKUPS-1800W-LCD: 18.9 kg
