Parameters

• Model Name

  TS1200 Pro Series

• Visual Indicator

  LED Indicator
  Steady green = Open
  Steady red = Close

• Audio Indicator

  Internal buzzer

• Lane Type

  Dual lane (support bi-directional)

• Lane Width

  550mm

• Barrier Movement Type

  Rotating (tripod)

• Tripod Length

  500mm

• Footprint (L*W)

  605 × 252mm

• Lid Material

  SUS304 stainless steel

• Lid Options

  Streamlined (with mount options)

• Lid Options Authentication Methods

  Fingerprint; RFID

• Chassis Material

  SUS304 stainless steel (T=1.2mm)

• Chassis Color

  Silver / gray

• Barrier Material

  SUS304 stainless steel

• Motherboard Function

  Tripod (drop arm) duration; access mode configuration

• Motherboard Communication

  Fire alarm port (relay) *1 ; RS485 port *1

• Controller

  C3-200 Plus (recommended); Inbio 260 Pro Plus or third-party controller subject to turnstile
  chassis space

• Credential Options

  Under Mount RFID Reader:ProID 10/ KR series
  Under Mount Fingerprint Reader: FR200 / FR1500

• Flow Rate

  RFID: 25 passengers per minute; Fingerprint: 20 passengers per minute

• Accessibility

  Adult; Children (with care); Disability (with care)

• Power Supply

  110V / 220V AC ±10% 50/60Hz; DC 12V

• Power Rating

  10VA (Standby); 40VA (Operation)

• Fire Signal

  Input for voltage free contact

• Noise Level

  Less than 60dB

• MTTR

  Less than 60 minutes

• MCBF

  2 million

• Weight

  Gross weight: 85kg
  Net weight: 65kg

• Dimensions ( L*W*H )

  1374 × 606 × 992mm

• Dimensions with Packing ( L*W*H )

  470 × 750 × 1100mm

• Operating Temperature

  -20°C to 70°C

• Operating Humidity

  0% to 80% RH (non-condensing)

• Certifications

  CE, FCC

• Ingress Protection Rating

  Tested to IPX4-level water resistance (self-lab test result)

• Supported Software

  ZKBio CVAccess / ZKBio CVSecurity (expands functionality for access control)

• Safety Levels

  Auto-locking tripod upon authenticaton failure; drop arm during power off or power outage

• Security Features

  Anti-tailgating

• Product Delivery

  Pre-assembled

• Application Environment

  Indoor / outdoor (if sheltered)

• Site Preparation

  Flat level finished floor (base plate in options for unfinished floor)

• Security Level

  Medium

• Emergency Mode

  Support (drop arm)

• Packing Material

  Wooden box (standard)
