Model Name
Comet-S1000
Comet-S1200
-
Audio Indicator
Internal buzzer
-
Visual Indicator
LED strip along the lid (7 Colour RGB, Customizable)
blue = stand by
steady green = normal use
steady red = door closing
flashing red = alarm
-
Display
1 or 2*7" ISP touch monitor (Under mount facial recognition version only)
-
Lane Type
Comet-S1000: Single lane
Comet-S1200: Dual wings (with comet-1000)
-
Lane Width (mm)
660mm (Standrad)
900mm (Optional)
-
Barrier Movement Type
Swing
-
Motor
DC brushless motor
-
Movement Speed
0.8s per movement(open / Close timing)
-
Movement Accuracy
≤1.5 Degree per movement
-
Clutch
Mechanical clutch for anti-panic / anti-collision
-
Lid Material
Tempered glass (Black) (Standard)
-
Lid Options Authentication Methods
Streamlined under mount options: Fingerprint / RFID / QR Code / Fingerprint + RFID / Fingerprint+QR Code / Fingerprint+RFID+QR Code / Facial recognition with display
Top mount option: mounting pole (Compatible with ProFace X / SpeedFace V5L/ Elite Pass)
-
Chassis Material
Cast aluminium alloy (T=3mm)
-
Chassis Colour
Silver (Standard), gold (Optional)
-
Door Leaf Material
Clear acrylic (H*W 630*295mm (Standard))
Clear tempered glass (H*W 630*295mm)
-
IR Sensors
8 Pairs (Standard) (High position)
-
Motherboard Function
System configuration, access mode configuration, anti-pinch configuration, anti-tailgate configuration etc.
-
Motherboard Communication
Fire alarm port(relay)*1, RS485 port*1
-
Controller
PGIC controller (Recommendation)
Others depends on dimensions fitting in (Optional)
-
Credential Options
Under mount RFID reader: (support model: ProID series, Armatura EP10C & Armatura EP20 series)
under mount QR code reader: QR500
under mount fingerprint reader: FR1200 / FR1500
under mount facial recognition terminal: G4 Pro
Top mount facial recogntion terminal: ProFaceX / Elite Pass / SpeedFace V5L
-
Flow Rate
RFID: 30 passengers per minute
QR Code: 30 passengers per minute
Fingerprint: 20 passengers per minute
Face: 15 passengers per minute
-
Accessibility
Under mount facial recognition version: adult, children, disability rest of the versions: adult, children (with care), disability (with care)
-
Power Supply
110V / 220V AC @ 50Hz to 60Hz
-
Power Rating
20 VA (Stand by)
120 VA (Operation)
-
Fire Signal
Input for voltage free contact
-
Noise Level
Less than 60 dB
-
MTTR
Less than 60 minutes
-
MCBF
6 million
-
Gross Weight
Comet-S1000: 130kg
Comet-S1200: 80kg
-
Net Weight (kg)
Comet-S1000: 100 kg
Comet-S1200: 65 kg
-
Dimension (L*W*H)
1500*115*1000mm (Standard)
-
Working Temperature
-28°C to 60°c
-
Working Humidity
95% RH (non-condensing)
-
Certifications
CE, FCC
-
Ingress Protection Rating
N/A (Waterproof and dustproof)
N/A (Barrier only) (Vandal ressistant)
-
Supported Software
ZKBio Access / ZKBio CVSecurity (Depends on equipped access controller)
-
Safety Features
Safety force sensing; Lower safety sensors; Accurate presence sensing ; Emitter/ receiver infrared sensors technology; Logic voltage 24V DC; Voltage free contact input for fire alarm fail state; Auto opening on power off; Anti-panic push opening in operation; Wide walkway for wheelchair or easier access; Accompanied wheelchair or child passage management (under mount facial recognition version)
-
Security Features
Anti-intrusion, Anti-tailgating, Wrong way enter alarm, Automatically close door no one pass
-
Product Delivery
Pre-assembled
-
Application Environment
Indoor
-
Site Preparation
Flat & level finished floor (Base plate in options for unfinished floor)
