· Supports multiple biometric authentication methods, including facial authentication, palm authentication (coming soon), fingerprint authentication, QR code (dynamic and static), and RFID verification.
· Expanded template capacity: 100,000 users, 100,000 card templates, 30,000 fingerprint templates, 100,000 face templates, and 20,000 palm templates (coming soon)
· Anti-spoofing algorithm that defends against print attacks, (laser, color, and B/W photos) and video attacks.
· Dual-frequency (125 kHz & 13.56 MHz) card module ensures seamless compatibility with a wide range of tech cards.
· IP66-rated waterproof & dustproof protection, IK07 vandal resistance, engineered to perform reliably across a wide operating temperature range of −30°C to 60°C (−22°F to 140°F).
· Built-in PoE power supply and equipped with dual-frequency wireless network, 4G module(optional) for flexible deployment.
· Supports Wiegand and RS-485 interfaces for external reader expansion.
· Supports encryption of all biometric credentials and personal information transfer that reaches AES-256 standard.
· Android LCDP with 3rd-party application integration, compatible with Android 14.0 OS.
· HD video door phone function via SIP Protocol (Version 2.0).
· Features120° wide-angle binocular camera for broader field of view, built-in intelligent noise-reduction algorithm for clear voice communication.
· AI Assistant capabilities: features on-device processing and with cloud-based intelligence (coming soon).
System
Operating System
Android 14.0
CPU
1.8 GHz quad-core processor
Storage
4GB RAM, 64GB ROM
SDK
Android LCDP, AC PUSH SDK
Basic
Communication
TCP/IP, 4G (optional), SIP 2.0 Protocol, Wi-Fi (IEEE 802.11 ac/a/b/g/n)@2 .4GHz & 5GHz)
Cellular Network
4G LTE-FDD: B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/66/71
4G LTE-TDD: B34/38/39/40/41
Display
8-inch IPS TFT LCD color multi-touch screen (700cd/m²)
Camera
2MP Binocular camera, 120° wide-angle, 1280 x 800 resolution
QR Code
Dynamic QR codes on the ZKBio Zexus Mobile App
Card Type
Dual frequency, 125KHz ID & 13.56MHz IC / DesFire
HID Prox / HID iClass (coming soon)
Firmware
User Capacity
100,000
Face Templates Capacity
100,000
Palm Templates Capacity
20,000 (Coming soon)
Fingerprint Capacity
30,000
Card Capacity
100,000
Transaction Capacity
2,000,000
Standard Firmware Functions
Record Query, Access Levels, Groups, Holidays, Duress Mode, Anti-Passback, Anti-Spoofing, Customization of Wallpaper & Screen Saver,Tamper Switch
Alarm, Multiple Authentication Methods,Video Intercom (ZKTeco Private Protocol via TCP/ lP, and SIP Client via SIP 2 .0)
Language
English, Arabic, Farsi, Spanish, Portuguese, Russian,Thai, French, Indonesian, Japanese, Korean,Vietnamese,Turkish, Traditional Chinese
Software
ZKBio CVSecurity V6.8.0; ZKBio Zexus (Mobile App)
Performance
Ingress Protection Rating
IP66, IK07
Card reading distance
1cm-5cm
Facial Authentication Distance
0.3m-1.2m (Human height 0.9 m to 2.4 m)
Facial Authentication Time
< 1s
Facial Authentication
1:1, 1:N
Facial Authentication Algorithm
ZKFace VX5630
Facial Authentication FRR
1%
Facial Authentication FAR
0.01%
Fingerprint Sensor Type
Optical
Fingerprint Authentication Time
≤ 0.5s
Fingerprint Authentication Method
1:1, 1:N
Fingerprint Authentication Algorithm
ZKFingerprint V10.0
Fingerprint Authentication FAR
0.0001%
Fingerprint Authentication FRR
0.01%
Interface
USB
1; USB 2.0 (for OTA)
Power Adapter
12V 3A
Ethernet
RJ45,1000M
RS-485
1 (For ZKTeco Reader)
Wiegand Input
1
Wiegand Output
1
Auxiliary input
1
Sensor
1
Lock 1
1 (Controlled)
Lock 2
1
Exit Button
1
Alarm
1
Power Output
1, 12V
Reset Button
1
External Battery Detection
1(Reserved)
External DC Detection
1(Reserved)
External AC Detection
1(Reserved)
Microphone
2
Speaker
1
General
Power Supply
12V 3A; PoE (IEEE 802.3 at)
Dimensions
277.9 x 134.9 x 34.3mm
Operating Temperature
-30°C to 60°C (-22°F to 140°F)
Operating Humidity
10% to 90% RH (non-condensing)
Operating Environment
Outdoor / Sheltered Outdoor
Gross Weight
2.3 kg
Installation Method
Wall-mounted (Compatible with Asian Gang-Box / Single Gang-Box; Standard) or Turnstile top-mount bracket (Compatible with Rots-02; Optional)
Certifications
ISO14001, ISO9001,CE, FCC, Equivalent to RoHS
Order ID
AC01-PF341H-44
(Silver and above members can download after logging in)
GL_FaceTima 8_Installation Guide_20260916
Installation Guide
1.62MB
2026-09-18
GL_FaceTima 8_User Manual_20260916
User Manual
11.5MB
2026-09-18
GL_FaceTima 8_Quick Start Guide_20260916
Quick Use Guide
5.2MB
2026-09-18
GL_FaceTima 8_Datasheet_20260917
Datasheet
1.19MB
2026-09-18
