Model
SL02-ZL140H
-
Material
-
Housing Material
Aluminum Alloy
-
Front Panel
ABS
-
Color
Black
-
Mortise Lock
-
Type
American Standard
-
Backset
62mm (2-7/16")
-
Axe Distance
Lever to Cylinder: 95mm (3-3/4"),
Lever to Thumbturn: 62mm (2-7/16")
-
Square Spindle
8x8mm square
-
Faceplate (H×W)
26×204 mm (1-1/41" x 8-1/32"), squared standard
-
Built-in Detectors
Latch Bolt, Deadbolt, Cylinder
-
Technical
-
Unlocking Methods
Card, Web Application, Mechanical Key Backup
-
Capacity
Event Log: 500 entries (Auto-overwrite)
-
Card Reader
S50/S70 IC Card @13.56 MHz
-
NFC Supported
Yes ( ISO/IEC 14443 A)
-
Encoder
D147-H
-
Audio Prompt Language
English
-
Wireless Communication
Zigbee 3.0 (IEEE 802.15.4)
-
Power Supply
4 × LR6 AA (Alkaline recommended only)
-
Battery Life
Approximately 1 year and 7 months
(* Based on lab testing: 10 daily cycles with deadbolt actuation and Zigbee connected.)
-
Supported Software
ZKBio CVSecurity SmartLock
-
Door Compatibility
-
Door Type
Swing Mortise Door
-
Door Thickness
40 to 63 mm (Standard)
-
Door Swing
Right Inward (Standard). (For non-standard door swing, please specify at purchase for proper fit.)
-
General
-
Net Weight
2.3 kg
-
Gross Weight
2.7 kg
-
Product Dimensions (H×W×T)
Exterior: 330 × 71 × 22 mm
Interior: 330 × 71 × 22 mm
* Excluding lever height: 41 mm
-
Package Dimensions (L×W×H)
460 × 240 × 95 mm
-
Operating Temperature
-20°C to 55°C (-4°F to 131°F)
-
Operating Humidity
5% to 95% RH (Non-condensing)
-
Certifications
CE, FCC
-
Package Contents
Front/Rear Trim;
Washer; Lock Body Kit (Includes mortise, strike plate, locking box);
Lock cylinder Kit (Includes 2 mechanical keys);
Studs & Screws Kit; IC Card * 2; Installation Template;
Installation Guide
