Model
E-LPRC500
-
Algorithm
-
License Plate Capture Rate
95%
-
Recognize Rate
≥99.9% (Typical Scene + Typical License Plate)
-
Car Speeds
0~25KM/h
-
Recognize Speed
Less than 100ms
-
Plate Type
Over 130 country and region
-
Target Features
Number \ Color \ Type \ Size
-
License Plate Anticounterfeiting
Abnormal license plate (mobile phone photo and printing) alarm is supported
-
Unlicensed Vehicles
Support unlicensed vehicles
-
License Plate Allow List
Support accurate and intelligent fuzzy matching of allow list license
-
-
Basic Configuration
Built-in intelligent ISP algorithm, intelligent optimization and dimming, intelligent adaptation to complex scenes
-
Video / Audio
-
Video Compression Standards
H.264/ H.265 / MJPEG
-
Resolutions
640*360 / 704*576 / 1280*720 / 1920*1080
-
Video Bitrate
512Kbps~5000Kbps
-
Frame Rate
1~25FPS
-
Audio Coding
G.711/AAC
-
Protocols
-
Protocols
SDK / ONVIF / HTTP / RTSP / TCP / IP / UDP / RS485 / IO/ NTP / VPN / FTP / UPNP
-
-
Image Sensor
5MP CIS
-
Low light
0.1LUX color (with fill light)
-
Resolution
2880(H) x 1620(V)
-
Electronic shutter
0-1ms or customized
-
Lens
6mm Fixed Lens
Optional 2.8~12mm / 7~22mm / 5~50mm Lens
-
Lens interface
M12
-
Image Configuration
Brightness, contrast, saturation, image flip, exposure time, etc.
-
Noise Reduction
Support 2D / 3D noise reduction
-
WDR
Support
-
Ports / Button
-
Network
1 * 10 / 1000Mbps Adaptive RJ45 port
-
IO Input
4 channels
-
RS485
2 channels
-
TF-card
1 TF card slot, supports up to 256GB
-
Bluetooth
Support
-
LCD Driver
Optional
-
Voice Intercom
Optional
-
Reset
1* RESET Button
-
Status Light
Support
-
Storage
-
Storage
32G
-
Reliability
-
Operating Temperature
-30°C ~70°C
-
Power Supply
Integrated: 12V DC 2A for basic configurations (without speakers, screens and other high power consuming components)
Module: 12V DC 5A for extended configurations (with speakers, screens and other high-power components)
-
Power Consumption
Integrated: Power consumption ≤ 8W (basic set, including fill light, excluding speakers, screen and other high power consumption components)
Module: Power consumption ≤ 55W (extended set with speakers, screen and other high power consumption components)
-
Protection Standard
Integrated: IP65
Module: /
-
Dimensions
-
Dimensions (L*W*H)
Integrated: 440mm * 144mm * 103mm
Module: 109mm * 149mm * 72mm
