SpeedFace-V5L Series

The SpeedFace-V5L Series employs intelligent engineering facial authentication algorithms and cutting-edge computer vision technology. It supports different versions of SpeedFace-V5L with large capacity and speedy authentication to satisfy your needs. SpeedFace-V5L[QR] comes with a QR code module to support Dynamic QR code via ZKBio CVAccess Mobile APP, while the SpeedFace-V5L-RFID standard ID card verification function.

SpeedFace-V5L Series uses touchless authentication technology and can identify individuals even when wearing masks, making it a hygienic option. Additionally, it has an advanced anti-spoofing algorithm that can detect fake photos and videos.

SpeedFace-V5L Series features a video intercom function with SIP protocol (Version 2.0) for compatible with video intercom indoor unit and supports ONVIF protocol to connect to ONVIF NVR for Video surveillance and recording. Moreover, it is compatible with ZKBio Zlink Mobile APP & ZKBio Zlink-Web when switching to BEST protocol.

Parameters

Model

SpeedFace-V5L
SpeedFace-V5L-RFID
SpeedFace-V5L[QR]
Order ID

SpeedFace-V5L: AC01-SP14H-P47
SpeedFace-V5L-RFID: AC01-SP12H-P47
SpeedFace-V5L[QR]: AC01-SP15H-P47
Display

5"@ ISP Color LCD Screen (720*1280)
Camera

Binocular Camera @ 2MP WDR
Operation System

Linux
Hardware

SpeedFace-V5L: CPU: Quad Core A55 @1.2GHz; RAM: 1GB; ROM: 8GB; Supplement Light: Yes; Virtual Keypad: 16 Keys; Fingerprint Sensor: Z-ID; Casing Color: Metallic silver
SpeedFace-V5L-RFID: CPU: Quad Core A55 @1.2GHz; RAM: 1GB; ROM: 8GB; Supplement Light: Yes; Virtual Keypad: 16 Keys; Casing Color: Metallic silver
SpeedFace-V5L[QR]: CPU: Quad Core A55 @1.2GHz; RAM: 1GB; ROM: 8GB; Supplement Light: Yes ; Physical Keypad: 16 Keys; Casing Color: Metallic silver
Authentication Method

SpeedFace-V5L: Fingerprint / Face / Card / Password (Virtual Keypad)
SpeedFace-V5L-RFID: Face / Card / Password (Virtual Keypad)
SpeedFace-V5L[QR]: Face / Card / Password (Virtual Keypad)
Fingerprint Template Capacity

SpeedFace-V5L: 10,000 (1:N)
SpeedFace-V5L-RFID: /
SpeedFace-V5L[QR]: /
Face Template Capacity

10,000 (1:N)
Card Capacity

10,000 (1:N)
User Capacity

10,000 (1:N)
Transaction Capacity

200,000 (1:N)
Max. User Password Length

8 Digits
Biometric Authentication Speed

SpeedFace-V5L: less than 0.5 sec (Fingerprint) ; less than 0.35 sec(Facial Authentication)
SpeedFace-V5L-RFID: less than 0.35 sec (Facial Authentication)
SpeedFace-V5L[QR]: less than 0.35 sec (Facial Authentication)
Touchless Biometric Recognition Distance

30cm to 170cm (Facial authentication)
False Acceptance Rate (FAR) %

SpeedFace-V5L: ≤0.01% (Facial authentication) ; ≤0.0001% (Fingerprint)
SpeedFace-V5L-RFID / SpeedFace-V5L[QR]: ≤0.01% (Facial authentication)
False Rejection Rate (FRR) %

SpeedFace-V5L: ≤0.02% (Facial authentication) ; 0.01% (Fingerprint)
SpeedFace-V5L-RFID / SpeedFace-V5L[QR]: ≤0.02% (Facial authentication)
Biometric Algorithm

SpeedFace-V5L: ZKFace V3.6 ZKFingerprint V13.0 (Standard) / V10.0 (Optional)
SpeedFace-V5L-RFID \ SpeedFace-V5L[QR]: ZKFace V3.6
Card Type

SpeedFace-V5L:
ID Card@125kHZ (Optional); IC Card@13.56 MHz (Optional);

Optional Multi-Tech Module:
Module1: ID & IC & DESFire EV1 / EV2 & Felica; (125 kHz & 13.56 MHz Dual Frequency); Module 2: ID & IC & DESFire EV1/EV2 & FeliCa & HID Prox & HID iClass (125 kHz & 13.56 MHz Dual Frequency)

SpeedFace-V5L-RFID \ SpeedFace-V5L[QR]:
ID Card@125kHZ (Standard); IC Card@13.56 MHz (Optional)

Optional Multi-Tech Module:
Module1: ID & IC & DESFire EV1 / EV2 & Felica; (125 kHz & 13.56 MHz Dual Frequency)
Module 2: ID & IC & DESFire EV1/EV2 & FeliCa & HID Prox & HID iClass
(125 kHz & 13.56 MHz Dual Frequency)
QR Code

SpeedFace-V5L: /
SpeedFace-V5L-RFID: /
SpeedFace-V5L[QR]: Dynamic QR codes on the ZKBio; CVAccess mobile application
Communication

TCP/IP*1
Wi-Fi (IEEE802.1b/g/n/a/ac/ax) @ 2.4 GHz / 5 GHz (Optional)
Wiegand (Input & Output)*1
RS485: ZKTeco RS485*1*
Aux Inputs *1, Aux Outputs *1, Electric Lock*1, Door Sensor*1, Exit Button*1, Alarm*1
Standard Functions

ADMS, DST, Photo Capture, Event Photo Capture, Up to 14-digit User ID, Access Levels, Groups, Holidays, Anti-Passback, Record Query, Tamper Switch Alarm, Multiple Verification Methods, T9 Keyboard (Input), AC Push and TA Push Protocol Switch, HTTPs / SSH Backend Access, Mask Detection
Optional Functions

Video Door Phone: SIP Client (Version2.0), ONVIF (Compatible with Profile S, Profile T, Profile G, Profile C, Profile Q & Profile A), Wi-Fi, Webserver
Video Intercom

Video Intercom(ZKTeco Private Protocol via TCP/lP)
Support Devices: Standalone Terminal: SpeedFace-V5L(Only ZAM230 Platform); Indoor Monitor: VT07-B01, VT07-B01-W

Video Intercom (Standard SIP Protocol)
Support Devices:
Standalone Terminal: SpeedFace-V5L(Only ZAM230 Platform); Indoor Monitor: VT07-B22L, VT07-B26L-W; Software: ZKBio CVAccess, BioTalk Pro; Mobile App: ZKBio Zlink, ZKBio Zexus
Access Control Interface

RS485 (DM10 Controller 1 Door Expansion / RS485 Card Reader / Biometric Reader)
Power Supply

DC 12V 3A
Operating Temperature

-10°C to 45°C (14°F to 113°F)
Operating Humidity

10% to 90% RH (Non-condensing)
Dimensions

202.93mm*91.93mm*21.5mm (L*W*H)
Net Weight

0.6 Kg
Supported Software

On-Premise Software: ZKBio CVAccess (AC PUSH) & ZKBio Time (TA PUSH)
Cloud-based Software: ZKBio Zlink (Supports Web Portal & Mobile App)
Installation

Wall-mount (Compatible with Asian Gang-box / Single Gang-Box)
Certifications

ISO14001, ISO9001, CE, FCC
