Parameters

• Panel properties

• Screen Size

  55 inch

• Backlight

  Direct-lit LED backlight

• Resolution

  1920 × 1080

• Brightness

  500 cd/m²

• Contrast Ratio

  3000 : 1

• Response Time

  8 ms

• Color Depth

  10-bit 1.07 Billion colors

• Life Span

  60,000 H (typ)

• Viewing Angle

  178° / 178° (horizontal / vertical)

• Bezel Width

  1.5 mm (top / left), 0.8 mm (bottom / right)
  *The above are approximate values, and the actual distance is related to the product and installation.

• Power

• Power Supply

  100 to 240 V, 50 to 60 Hz

• Power Consumption

  ＜ 230 W

• Operating Conditions

• Operating Temperature

  0 °C to 40 °C

• Operating Humidity

  10% to 90% (non-condensing)

• Interface

• Input

  USB × 1, HDMI IN × 1, DVI × 1, RS232 IN × 1

• Output

  RS232 OUT × 2

• General

• Material

  Metal

• Net Weight

  16.5 kg

• Dimensions(L*W*H)

  1213.5 × 684.5 × 60.1 (mm)

• Package Dimension (L*W*H)

  1360 × 260 × 815 (mm)

• Way to install

  Floor cabinet type, floor bracket type, and wall bracket type

• Else

• Fittings

  AC power cable, warranty card, network cable, hook, adjusting screw, remote controller (optional)

Download

(Silver and above members can download after logging in)

• Name
• Type
• Size
• Update Time

• PDF

  ZK-LED55A-2K-1.8MM_Datasheet_20251209

  Datasheet

  2.82MB

  2025-12-25
