Model
-
Display
2.4"@ TFT Color LCD Screen (240 * 320)
-
Operation System
Linux
-
Hardware
CPU: Dual Core@1.0GHz
RAM: 128MB; ROM: 256MB
Speaker: 8ohm±15% @1.0W
Physical Keypad: 17 Keys
Fingerprint Sensor: ZK Optical Sensor
-
Authentication Method
Fingerprint / Card / Password (Physical Keypad)
-
Fingerprint Template Capacity
3,000 (1: N)
-
Card Capacity
3,000 (1: N)
-
User Capacity
3,000 (1: N)
-
Transaction Capacity
200,000
-
User Password Length
6 - 8 digits
-
Biometric Authentication Speed
less than 0.5 sec (Fingerprint)
-
False Acceptance Rate (FAR) %
FAR ≤ 0.0001% ( Fingerprint; ZKFingerprint V10.0; ZKFingerprint V13.0)
-
False Rejection Rate (FRR) %
FRR ≤ 0.01% ( Fingerprint; ZKFingerprint V10.0; ZKFingerprint V13.0)
-
Biometric Algorithm
ZKFingerprint V13.0 (Standard) / V10.0 (Optional)
-
Card Type
ID Card @ 125 kHz (Standard)
IC Card @ 13.56 MHz (Optional)
Optional Multi-Tech Module:
Module1: ID & IC & DESFire EV1 / EV2; (125 kHz & 13.56 MHz Dual Frequency)
-
Communication
TCP/IP*1
Wi-Fi (IEEE802.11b/g/n/ax) @ 2.4 GHz (Optional)
Wiegand (Input or Output)*1
RS485: ZKTeco RS485*1
USB: Type A (USB Drive Only)*1
Aux Inputs*1, Electric Lock *1, Door Sensor*1, Exit Button*1, Alarm*1, Doorbell*1,
12V Output*1
-
Standard Functions
Webserver, ADMS, DST, Up to 14-digit User ID, Access Levels, Groups, Holidays, Anti-Passback, Record Query, Schedule Bell, Tamper Switch Alarm, Automatic Status Switch (Effective only under T&A rules), Multiple Verification Methods, AC PUSH and TA PUSH Protocol Switch, HTTPS / SSH Backend Access, T9 Keyboard (Input), SRB, Doorbell
-
Optional Functions
Wi-Fi (AP Mode), PoE, Wireless Doorbell
-
Access Control Interface
RS485 (RS485 Card Reader / Biometric Reader)
-
Operating Temperature
-5°C to 45°C
-
Power Supply
DC 12V 1.5A
PoE: IEEE 802.3at (Optional)
-
Operating Humidity
20% to 80% RH (Non-condensing)
-
Dimensions
205.7mm * 82.7mm * 33mm (L * W * H)
-
Gross Weight
0.76 Kg
-
Net Weight
0.42 Kg
-
Supported Software
On-Premise Software: ZKBio CVAccess (AC PUSH) / ZKBio Time (TA PUSH)
Cloud-based Software: ZKBio Zlink by default (Supports Web Portal & Mobile App)
-
Installation
Wall-mount (Compatible with Asian Gang Box / Single Gang Box), compatible with Rots-3 Stand / Rots-02 Bracket
-
Ingress Protection Rating
IP65 (waterproof and dustproof )
-
Certifications
ISO14001, ISO9001, CE, FCC, RoHS
-
Order ID
AC01-F34H-16
